FIG 62/FIG 62A
DESCRIPTION
ALLEN thermometers are designed to meet the industry high standard of quality and case of installation. The Allen name is synonymous with quality, reliability and superior performance.
FEATURES
CASING
Solid Brass Tube.
The nut on top of tube can be unscrewd, hence to replace the capillary tube when necessary.
GLASS INSERTS
Capillary tube of solid glass, approx. 4mm diameter with white background for easy reading.
FILLING
Standard column (from -30 °C to 50 °C), filled with blue spirit fluid.
IMMERSION TUBES
Standard type made of brass for temperature up to 50 °C.
Special stem material and temperature range are available upon request.
Standard length of immersion tube is 63.5mm and 101.6mm, and other lengths available upon request.
APPLICATION
- Air-conditioning system
- Hot and cold water piping system
- Hot air system
